Detailed Equipment Information
The freestanding Red Chili D™ quartz flash cure system uses medium-wave sealed tungsten filament quartz lamps that feature adjustable intensity, and it works with both automatic and manual screen printing presses. Instant-on flash cure technology conserves energy by reverting to standby status when the screen printing press is idle, and the curing lamps are divided into three flashing zones (except for the 1418 and 1618 models), which can be operated independently or in any combination. Using fewer flash cure zones on small screen print areas reduces ambient heat, lowers energy costs, and leads to faster substrate cooling. Flash cure duration can be controlled by a digital timer or by M&R’s exclusive InkSense™ substrate temperature sensor. Co-developed with a major sensor manufacturer, InkSense™ automatically shuts off the flash cure unit when the substrate reaches operator-set temperature. That helps prevent over-flashing, a major cause of dye migration and synthetic garment shrinkage. An adjustable sensor switch can be positioned on either side of the flash cure unit, activating the flash when the printing pallet approaches. Red Chili D also features a communication socket that gives operators two additional methods of controlling the flash: an optional communication cable can be used to control the flash directly from the press and an optional foot pedal control can be connected to the flash. The curing module is mounted on a height-adjustable floor stand that makes moving the flash fast and easy. All M&R screen printing flash cure units are UL Listed (built to specifications established by Underwriters Laboratories®)—UL), CE Certified (built to specifications established by the European Committee for Standardization®—CE), and backed by a limited two-year warranty.
For over 30 years M&R has helped countless screen printers realize their dreams by supplying them with innovative screen and digital printing products that stand the test of time. We have the right solutions, from pre-press to product finishing, for shops of all sizes. M&R equipment is designed and built with a commitment to quality, durability, and innovation, and is backed by unrivaled 24-hour service and support. With efficient systems integration from start to finish, it’s no surprise that year after year, print after print, M&R’s hard-working equipment is the choice of professional printers around the world.
