CAROUSEL/INDEXER
|
| • |
Clockwise or counterclockwise rotation available (specify at time of order)
|
|
|
CENTRAL OFF-CONTACT
|
| • |
Permits fast, incremental single-lever adjustment of all stations simultaneously
|
|
|
CERTIFICATION
|
| • |
CE & UL compliant: Built to specifications established by the European Committee for Standardization® (CE) and Underwriters Laboratories® (UL)
|
|
|
CONTROL CENTER
|
| • |
Countdown program indicates when operator-set index count has been reached
|
| • |
Independent print-start/print-finish setting automatically activates and stops printheads at the beginning and end of production runs
|
| • |
Multiple (1-9) print stroke capability
|
| • |
Multi-print in the up position
|
| • |
Onboard self-diagnostics
|
| • |
Real-time production data
|
| • |
Swiveling control arm with touch-screen display
|
|
|
INDEX SYSTEM
|
| • |
Pneumatically-driven indexer
|
|
|
PALLET SYSTEM
|
| • |
Composite pallets
|
| • |
Precise three-point pallet leveling system
|
| • |
Tool-free pallet locator speeds pallet changeover
|
| • |
Tool-free quick release pallet locks
|
|
|
PRINTHEADS
|
| • |
Four-point off-contact adjustment
|
| • |
Independent print/flood speed controls on each printhead simplify press setup
|
| • |
Pneumatically-driven printheads
|
|
|
REGISTRATION
|
| • |
Compatible with numerous registration systems, including M&R’s Tri-Loc® & Double Tri-Loc® and Newman Pin-Lock®
|
| • |
Enhanced front micro-registration adjustments with visual guides
|
|
|
REVOLVER PRINT PROGRAM
|
| • |
Automatically operates individual printheads in programmed sequence and allows multiple flashing without losing a printing position (U.S. Patent No. 5,595,113)
|
|
|
SCREEN CLAMPS & HOLDERS
|
| • |
Adjustable side frame holders accommodate a wide variety of screen sizes
|
| • |
Clamping system holds roller frames without special adapters
|
| • |
Manual clamps hold frames tight and allow rapid screen loading (pneumatic clamps on enhanced models)
|
|
|
SQUEEGEE/FLOODBAR
|
| • |
Angle and calibrated pressure adjustments are independently set
|
| • |
Front or rear print carriage stop position allows operator to leave screens clear or flooded (great for water-based inks)
|
| • |
Independent squeegee & floodbar speed adjustments
|
| • |
Manual squeegee pressure regulator (pneumatic pressure regulators on enhanced models)
|
| • |
Manual squeegee/floodbar clamps (pneumatic clamps on enhanced models)
|
| • |
Visual reference marks every 5 degrees simplify squeegee/floodbar angle adjustments
|
|
|
STROKE LENGTH ADJUSTMENT
|
| • |
Adjustable rear stroke length with tool-free adjustment maximizes print speed
|
|
|
WARRANTY, SERVICE AND SUPPORT
|
| • |
24-hour hotline is staffed 365 days a year
|
| • |
Access to M&R’s Training Center
|
| • |
One-year limited warranty
|
| • |
Parts & supplies are available online at store.mrprint.com
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
DESIGN & CONSTRUCTION
|
| • |
Designed & disassembled to fit through a 78 cm (31") doorway
|
|
|
FOOT PEDAL CONTROL
|
| • |
Allows indexing of the press using a foot pedal
|
| • |
Skip-Shirt foot pedal feature allows operators to avoid printing empty pallets
|
|
|
OPTICAL NO-SHIRT DETECTOR
|
| • |
Automatically prevents the press from printing on empty pallets (U.S. Patent No. 5,383,400)
|
| • |
Reduces misprints and minimizes press stoppage because of improperly loaded shirts
|
|
|
PRINTHEADS
|
| • |
Enhanced printhead option includes pneumatic squeegee/floodbar locks with tool-free angle adjustment, pneumatic screen frame locks, and pneumatic squeegee pressure regulator with pressure gauge
|
|
|
WARRANTY, SERVICE AND SUPPORT
|
| • |
Additional one-year limited warranty
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
Air @ 6,9 bar
(100 psi)
|
|
Diameter
|
|
Electrical Requirements 1
|
|
Maximum Frame Size
|
|
Maximum Image Area
|
|
Shipping Weight
|
|
Standard Pallet Size
|
|
Stations/Colors
|
|
|
|
|
|
|
|
|
|
|
|
|
